COMMERCIAL DOOR OPERATORS

Features Include

• Can lift rolling sheet doors as large as 14ft. high
• Perfect workhorse for larger sheet doors while still maintaining the signature slim profile
• Offers superior reliability, security and convenience
• 600N DC Motor
• Soft Start / Soft Close
• LED Courtesy Light
• Intelligent Safety System
• 12' Max Opening Height 9-1/2" Drum Doors or 180 sq. ft.
• 14' Max Opening Height 12" Drum Doors or 180 sq. ft.
• Battery Back-up Option Available
• Battery Back-up Recommended Doors > 10'-0"H
• Wall Station and 2-Remote Controls Included

Available for the following door models (Maximum size 180 sqft):

• Series 2000, 2500, 3100, 3400, and 3652 (Max Opening Height: 14')

Documents

• Product Brochure
• Instruction Manual

Features Include

• Weather-resistant housing.
• Designed for exterior mounted doors (cover recommended), this opener has a weather resistant rating of IP24.
• Secure and reliable transmitters.
• The TrioCode™ 128 transmitter system ensures secure and reliable home access. It transmits on three frequencies to defeat radio interference, and uses a 128-bit encryption protocol for the ultimate in security.
• Keyed & Electronic Lockout.
• As the Shed Master® can be installed in exposed locations, a keyed lockout is included to stop unwanted persons reaching over the fence and disengaging the door to manual mode. Also, the control panel can be similarly locked out to prevent unauthorized usage.
• This opener is top of its range with built-in
  intelligent features such as Intelligent Safety System and Door Profiling – meaning the door adjusts itself when opening and closing or if blocked.
• 12'6 max opening height

Available for the following door models (Maximum size: 165 sq. ft.):

• Series 2000
• Series 2500
• Series 3100
• Series 3400
• Series 3652

Documents

• Product Brochure
• Instruction Manual

Features Include

• Suitable for use on high rolling sheet doors
• Not only the most powerful opener in our range but it is also suitable for low side room installation
• Paves the way in control and connectivity delivering smart phone control in residential and commercial applications (as an additional upgrade)
• 1400N Short-term peak force
• Soft Start / Soft Close
• Slim fit design
• LED Courtesy Light
• Intelligent Safety System
• Smart Phone Compatible
• 110V Power required at every unit
• 300 sq-ft. Max Opening (Non Windlocked Doors)
• 236 sq-ft. Max Opening (Windlocked Doors)
• Battery Back-up Option Available
• Battery Back-up recommended doors > 10'-0"H
• Wall Station and 2-Remote Controls included

Available for the following door models:

• Series 2000, 2500, 3100, 3400, and 3652 (Max Opening Height: 20')

Documents

• Product Brochure
• Instruction Manual

Features Include

• Designed to suit a 12" drum wheel commercial series.
• Uses a low voltage DC motor, which is more quiet and efficient than standard AC motors.
• Fits neatly inside the torque tube of the roll-up door, requiring minimal additional side room.
• Features the latest in electronic technology combined with innovative engineering and a patented design.
• Electronic limits can not be "lost" or "erased" in the event of a power failure or interruption.
• Manufactured to exceed UL325 and CE requirements.
• The operator can be converted to manual operation with the simple movement of a lever, then operated with minimal effort with an 18:1 chain reduction hoist.
• The operator is controlled by a logic control which offers a soft start-soft stop feature, ensuring that the motors are not subjected to undue stress during starting and stopping sequence. The door will come to rest gently and smoothly, helping to prolong the motor life.
• Connections of external devices are simple and easy to complete with removable plug sockets, which allow the wiring to be done away from the logic controller and then simply plugged into the required position.

Available for the following door models (Maximum Size: 256 sq. ft.):

• Series 2000
• Series 2500
• Series 3100
• Series 3400
• Series 3652

Documents

• Product Brochure- Commercial
• Installation Guide- Commercial

Learn More>>

Features Include

• Designed to suit a 9-1/2" drum mini series.
• Uses a low voltage DC motor, which are more quiet and efficient than standard AC motors.
• Fits neatly inside the torque tube of the rolling door, requiring no additional side room.
• Features the latest in electronic technology combined with innovative engineering and a patented design.
• Electronic limits can not be "lost" or "erased" in the event of a power failure or interruption.
• Manufactured to exceed UL325 and CE requirements.
• Includes floor level- cable operated manual release.
• The operator is controlled by a logic control which offers a soft start-soft stop feature, ensuring that the motors are not subjected to undue stress during starting and stopping sequence. The door will come to rest gently and smoothly, helping to prolong the motor life.
• Connections of external devices are simple and easy to complete with removable plug sockets, which allow the wiring to be done away from the logic controller and then simply plugged into the required position.

Available for the following door models (Maximum Size: 168 sq. ft.):

• Series 1000
• Series 1100

Documents

• Product Brochure- Mini
• Installation Guide- Mini

Features Include

• Medium Duty Commercial Door Operator
• Integrated Time to Close (ITT)
• Chain Hoist with Electric Interlock for Manual Operation in an Emergency
• High Starting Torque Motor with Overload Protection
• 2 Year Warranty

Documents

• Product Brochure

Features Include

• Industrial Duty Commercial Door Operator
• Features MyQ Technology to Enable Monitoring and Control of the Facility Operators Via Mobile App
• Safeguards Facility Access with Rolling Code Technology, Opening for Registered Devices Only
• Floor Level Chain Hoist for Manual Operation in Emergency

Documents

• Product Brochure

Features Include

• Heavy Duty Industrial Gear Head Operator with Hoist
• Designed for 25 cycles/hour or 180 cycles/day
• Standard with Auxiliary Chain Hoist in the event of a power outage
• Standard with NEMA 1 Photo Eyes

Documents

• Product Brochure
